NX CAD

The industry leading product design software

About NX CAD

The NX Mach™ software products are prepackaged solutions delivering high-performance computer-aided design (CAD) capabilities of NX™ software, the leading solution for mechanical design. The NX Mach bundles are a functional basis for the integration with the state-of-the-art CAE solution Simcenter 3D.

NX CAD

NX CAD is at the heart of the digital twin within the Siemens Xcelerator. It provides an all encompassing product development process that enables quicker market gains, lower costs and improved product quality. All of this is possible through the high performance and capabilities available through NX CAD. The comprehensive preconfigured Mach solutions include high performance modeling, drafting and assembly design powered by synchronous technology and convergent modeling.
As a foundation within the Xcelerator portfolio, the NX Mach bundles can be integrally used with Simcenter 3D.

Contact us Get a trial


License options

As forerunner of the digital twin, the NX Mach bundles are all subscription based and can be bought via the online webshop. When you have specific questions or module requirements, feel free to get in contact with us.

Compare Mach bundles Online subscription More information




Benefits

  • Basis for integrated advanced CAE simulations with Simcenter 3D
  • Boosts product design efficiency
  • Accelerates mechanical design processes
  • Reduces design process waste
  • Improves design quality
  • Improves collaboration
  • End-to-end mechanical product design solutions with a rich set of supporting tools
  • High-performance modeling, drafting and comprehensive assembly design powered by synchronous technology and Convergent Modeling

Features

  • Single environment facilitates process from model to printed part
  • Comprehensive preconfigured solutions tailored for the full range of product design applications
  • Power and flexibility that supports virtually any design methodology, whether top-down or bottom-up
  • Cornerstone of a complete product development system
  • Foundation for product lifecycle management
  • Extendible with a selection of add-on application modules
  • Works with surface and facet geometry in the same CAD model

Why Femto Engineering

  • We’ve been a Siemens CAE Expert partner since 2006 and provide full-service sales and support to 100+ companies in the Benelux.
  • We use Siemens Digital Industries Software for our CAE consulting services. From simple to complex needs, our consultants will give advice on the right tools for you.
  • You can increase your proficiency through our tutorials and with the help of our dedicated support engineers.

We like to hear about your challenges, so we can advise you appropriately. Come and meet us!
